EZ Raider LW
Technical Specification
Display Panel:
Includes battery
operational function
keys (optional)
Hand Guard:
For maximum safety
Front Lighting: LED
Removable Seat
Compact and Easily
Foldable: For transport –
can fit into
the trunk of a pick-
up/station wagon
Front and Rear
Braking System
Wheels: 120/90-10
Battery: Lithium-Ion
60V – 1740 W/h
Motor: 1200 W
motor in both
rear wheels
Standing Board
Length
161 cm / 63"
Width
67 cm / 26"
Height
127 cm / 50"
Height Folded
64 cm / 25"
Estimated Dry Weight
95 kg / 209 lb
Max Speed
Up to 40 Km/hr/24.8 miles
Max Range
35 Km/21.5 miles
Download our brochure for additional details and full specifications.
Performance
The EZ Raider offers an all-new driving experience. The meticulous development and our innovative features guarantee a smooth ride on any terrain. Traveling on rough terrain or
cruising in the urban view, you can rest assured this vehicle won’t let you down!
Terrains
Maintenance
Safety
Design
Functional Uses
The EZ Raider LW is our classic model. Cruise with power and style down paved ways or enjoy the off-road with the best 4 wheel electric scooter there is. With 2 electric engines you have 2400 watt at your disposal, that’s almost 3.5 horse power!
Tourism
Personal Mobility
Urban Use
Disabled People
Technology
The EZ Raider sets a new standard in personal mobility, placing state of the art technology right in your grip. So much more than an off-road vehicle, the EZ Raider is a completely new, patent protected concept in maneuverability. Intuitive to operate, this fully electric ATV is designed for use in both urban environments and backwoods trails. Features include advanced all wheel’s drive (AWD), hub motors with direct wheels transmission, energy efficiency capability and payload capacity about twice vehicle weight, all integrated with a unique and simplicity of design.
Motor
AWD system with two or four (based on the model) direct transmission wheel hub motors that feed direct torque to each wheel independently, providing maximum efficacy.
Controllers
Fully functional EV controllers for a smooth driving experience, with a specific controller for each motor to maximize efficiency.
Energy Efficiency
Regenerative braking system captures kinetic energy from the vehicle’s momentum to recharge the battery.
Braking System
BREAKING SYSTEM Hydraulic brake discs on each wheel, front and back brake handles for maximum control and improved safety, including hand brake capability
Battery
Lithium-Ion 60-volt battery, high capacity 1740 W-Hr / 2700 W-Hr.
Suspension Mechanism
Patent-protected 3D suspension mechanism long travel to overcome obstacles in difficult off-road conditions for extreme maneuverability.
Payload Capacity
Capable of hauling about twice its weight, maximum 200 kg.
