EZ Raider HD2
Technical Specification
Display Panel:
Includes battery
operational function
keys (optional)
Hand Guard:
For maximum safety
Front Lighting: LED
Compact and Easily
Foldable: For transport –
can fit into the
trunk of a pick-up
/station wagon
Front and Rear
Braking System
TIRE 20X6 -10
EZRAIDER BRAND
Battery: Lithium-Ion
60V – 2700 W/h
Motor: 1200 W motor
in both rear wheels
Standing Board
ELECTRICAL CONNECTION
TO THE E-CART
HD LUGGAGE RACK
Length
165 CM / 65"
Width
70 CM / 27.5"
Height
130 CM / 51"
Height Folded
70 CM / 27.5"
Estimated Dry Weight
110 KG / 242 LB
Max Speed
Up to 40 Km/hr/24.8 miles
Max Range
80 Km/49.7 miles
Download our brochure for additional details and full specifications.
Performance
The EZ Raider offers an all-new driving experience. The meticulous development and our innovative features guarantee a smooth ride on any terrain. Traveling on rough terrain or
cruising in the urban view, you can rest assured this vehicle won’t let you down!
Terrains
Maintenance
Safety
Design
Functional Uses
Driving through town or extreme off-roading? The EZ Raider HD2 is your ideal choice! With double the power you’ll be reaching almost 50 miles with one charge. Our compact, unique design makes us the ultimate solution for all your personal mobility needs; a sturdy, dependent work tool, or a rugged but safe extreme sports vehicle, The EZ Raider can be used by individuals or in groups for fieldwork, security detail and fun.
Security
Agriculture
HLS
Technology
The EZ Raider sets a new standard in personal mobility, placing state of the art technology right in your grip. So much more than an off-road vehicle, the EZ Raider is a completely new, patent protected concept in maneuverability. Intuitive to operate, this fully electric ATV is designed for use in both urban environments and backwoods trails. Features include advanced all wheel’s drive (AWD), hub motors with direct wheels transmission, energy efficiency capability and payload capacity about twice vehicle weight, all integrated with a unique and simplicity of design.
Motor
AWD system with two or four (based on the model) direct transmission wheel hub motors that feed direct torque to each wheel independently, providing maximum efficacy.
Controllers
Fully functional EV controllers for a smooth driving experience, with a specific controller for each motor to maximize efficiency.
Energy Efficiency
Regenerative braking system captures kinetic energy from the vehicle’s momentum to recharge the battery.
Braking System
Regenerative braking system captures kinetic energy from the vehicle’s momentum to recharge the battery.
Battery
Lithium-Ion 60-volt battery, high capacity 1740 W-Hr / 2700 W-Hr.
Suspension Mechanism
Patent-protected 3D suspension mechanism with long travel to overcome obstacles in difficult off-road conditions for extreme maneuverability.
Payload Capacity
Capable of hauling about twice its weight, maximum 200 kg.
Mobility Without Limits.
Costumers Reviews
It’s a beast! The HD4 goes through mud, creeks, mountain hills… and will pull anything you need… It has enough power to get you to the moon!
RICHARD, HEAD HUNTER
This thing lives and breathes raw power. I am yet to experience something this machine can not do! Ground clearance great… destroys the mud… EZRAIDER HD4 is very predictable, and a blast to drive!!
IAN, ADRENALINE JUNKIE
I bought my HD4 about eight months ago. It literally revolutionized the way we work on the farm. Zero problems, a very reliable machine that is just fun to work with…
JAMES, FARMER
